Zigbee to RS485 converter

Zigbee to RS485 converter

ASS300420100

Brand: Victron

Wireless Communication: Eliminates the need for wired connections between energy meters and GX devices. Easy Installation: Simple Zigbee and RS485 connections for quick setup. Seamless Integration: Compatible with Victron Energy Meters for efficient energy monitoring. Enhanced Monitoring: Provides real-time data transmission for accurate energy usage analysis. Reliable Performance: Designed for stable and consistent wireless communication. Dimensions: 70 x 24 x 67mm Weight: 0.157kg

In stock

This is pre-order - Available in 7 – 10 days

£109.00 GBP
£109.00 GBP
Sale Sold out

Product Details

The Victron Zigbee to RS485 Converter is designed to facilitate wireless communication between Victron Energy Meters and GX devices. By connecting the converter to the GX device via Zigbee and to the energy meter via RS485, it enables seamless energy monitoring without the need for complex wiring. This converter is ideal for installations where wired connections are impractical or undesirable, providing flexibility and ease of setup.

Once connected, the converter allows for real-time data transmission from the energy meter to the GX device, enabling accurate monitoring of energy usage. This functionality is particularly beneficial for off-grid systems, marine applications, and other scenarios where efficient energy management is crucial.

Product Specifications

Technical Parameters

  • Power Input: DC 5V – 28V
  • Operating Temperature Range: -40°C to +85°C
  • UART Baud Rates: 9600, 19200, 38400 (Default), 57600, 115200 bps
  • Operating Current (Send): 120 mA Max
  • Operating Current (Receive): 45 mA Max
  • Standby Current: 40 mA Max
  • Receiver Sensitivity: -110 dBm
  • Core Chipset: CC2530F256 (256K FLASH)
  • Configurable Node Types: Coordinator, Router (Default: Router)

Radio & Wireless Specifications

  • Wireless Protocol: Zigbee 2007
  • Default Radio Frequency: 2460 MHz (Channel 22)
  • Frequency Range: 2405 MHz – 2480 MHz (Step: 5 MHz)
  • Transmission Distance: 1600 meters (Visible, open transmission distance)
  • Default PAN ID: 0x199B

Mechanical Specifications

  • Communication Interface: RS485 (Terminals: B, A, GND)
  • Dimensions: 70 x 50 x 24 mm
  • Status Indicators: Integrated LEDs for TX/RX data and Active status
  • Configuration Keys: Reset and Function KEY for easy setup
  • Installation: Features an integrated mounting flange for secure placement

Zigbee to RS485 converter – Data Sheet
