Victron Energy Gel Deep Cycle Battery 12V 220Ah – BAT412201104
Victron Energy Gel Deep Cycle Battery 12V 220Ah – BAT412201104
SKU:BAT412201104
Brand: Victron
In stock
This is pre-order - Available in 7 – 10 days
Couldn't load pickup availability
Product Details
Product Details
The Victron Energy Gel Deep Cycle Battery 12V 220Ah (BAT412201104) is engineered for demanding applications where reliability and longevity are paramount. Its sealed VRLA (Valve Regulated Lead Acid) design with gel electrolyte ensures maintenance-free operation and safe performance.
This battery is particularly suitable for off-grid solar systems, marine applications, and other setups requiring deep discharge capabilities. With a design life of up to 12 years and a low self-discharge rate of less than 2% per month at 20°C, it offers peace of mind and consistent power over time.
The use of lead calcium grids enhances the battery's durability and performance, making it a trusted choice for those seeking a high-quality deep cycle battery solution.
2 Year Warranty
Maintenance Free
Product Specifications
Product Specifications
Electrical Specifications
- Nominal Voltage: 12 V
- Nominal Capacity (20 hr. discharge @ 25°C): 220 Ah
- CCA @ 0°F: 600
- RES CAP @ 80°F: 220
Performance & Design Life
- Technology: Flat plate GEL
- Float Design Life: 12 years at 20°C
- Cycle Design Life (80% Discharge): 500 cycles
- Cycle Design Life (50% Discharge): 750 cycles
- Cycle Design Life (30% Discharge): 1800 cycles
Charging Specifications
- Absorption Voltage: 14.1 – 14.4 V
- Float Voltage: 13.5 – 13.8 V
- Storage Voltage: 13.2 – 13.5 V
- Recommended Charge Current: Should preferably not exceed 0.2 C (44 A for this 220 Ah model).
- Temperature Compensation: -24 mV/°C for a 12V battery (Required if battery temperature is expected to be < 10°C or > 30°C for long periods).
Mechanical Specifications
- Dimensions (h x w x d): 522 x 238 x 240 mm
- Weight: 66 kg
- Terminals: Copper
Key Features
- Enhanced Longevity: Optimized for a high number of charge-discharge cycles and extended float life.
- VRLA Technology: Maintenance-free operation with safety valves to prevent excessive gas pressure.
- Adaptive Charging Support: Performs best when used with Victron 4-step adaptive chargers featuring Battery Safe and Storage modes to prevent overcharging and plate corrosion.
