Victron 20W Solar Panel – Monocrystalline Panel

Technical Specifications

Combined for SKUs: SPM040201200

Allowable Hail Load Speed: 23 m/s

Allowable Hail Load Weight: 7.53 g

Cell Type: Polycrystalline

Depth: 25 mm

Frame Material: Aluminium

Height: 440 mm

Junction Box Type: PV-LH0805

Max Power Current: 1.09 A

Max Power Voltage: 18.5 V

Max System Voltage: 1,000 V

Nominal Power: 20 W

Number Of Cells In Series: 36

Number Of Panels Per Pallet: 380

Open Circuit Voltage: 22.6 V

P VCable Connection Type: No Cable

P VOutput Tolerance: 3 %

Product Warranty: 5 y

Short Circuit Current: 1.49 A

Smallest Packaging Unit: 1

Warranty80Output: 10 y

Warranty90Output: 10 y

Weight: 1.9 kg

Width: 350 mm

Source: Victron
