Victron 12V 60Ah AGM Deep Cycle Battery

Victron 12V 60Ah AGM Deep Cycle Battery

BAT412550084

Brand: Victron

High-current capability: Delivers excellent power for inverters, winches, thrusters and more. Long cycle life: Up to 1,500 cycles at shallow discharge (30 percent). Extended float life: 7–10 years of reliable performance in float applications. Low self-discharge: Under 2 percent per month at 20 °C, ideal for long storage. Durable, maintenance-free build: Sealed VRLA design with M8 copper terminals. Dimensions: 229 x 138 x 227 mm Weight: 20 kg

In stock

This is pre-order - Available in 7 – 10 days

£147.00 GBP
£147.00 GBP
Sale Sold out

Product Details

The Victron 12 V 60 Ah AGM Deep Cycle Battery is a rugged, maintenance-free energy solution built for demanding mobile, off-grid, and high-current applications. Using flat-plate AGM (Absorbent Glass Mat) technology, this sealed valve-regulated lead-acid (VRLA) battery delivers excellent performance with minimal self-discharge, while offering robust recovery from deep discharge cycles.

With a nominal voltage of 12 V and a rated capacity of 60 Ah (20-hour rate at 25 °C), it strikes a reliable balance between energy storage and power output. The internal resistance is very low, making it ideally suited for high-current tasks such as inverters, winches, bow thrusters, or for occasional engine starting. At 20 kg and compact dimensions of 229 × 138 × 227 mm, it is easy to mount in tight spaces without compromising on capacity.

Durability is a key strength: the battery’s float life is rated at 7–10 years at 20 °C, and it can withstand up to 1,500 cycles at 30% depth of discharge, 600 cycles at 50%, and 400 cycles at 80%. Thanks to its lead-calcium grid design and high-purity materials, self-discharge is kept below 2% per month at 20 °C, meaning you can store it for extended periods without recharging.

Terminals are copper, with M8 bolt-through configuration ensuring secure and reliable connection, even under aggressive vibration or high loads.

In short, the Victron 12 V 60 Ah AGM Deep Cycle Battery is a trustworthy, long-life power source tailored for professional and trade use, especially where reliable deep cycling or high current bursts are needed.

Product Specifications

Electrical Specifications

  • Nominal Voltage: 12 V
  • Nominal Capacity (20 hr. discharge @ 25°C): 60 Ah
  • CCA @ 0°F: 280
  • RES CAP @ 80°F: 80

Performance & Design Life

  • Technology: Flat plate AGM
  • Float Design Life: 7 – 10 years at 20°C
  • Cycle Design Life (80% Discharge): 400 cycles
  • Cycle Design Life (50% Discharge): 600 cycles
  • Cycle Design Life (30% Discharge): 1500 cycles

Charging Specifications

  • Absorption Voltage (Normal): 14.2 – 14.6 V
  • Absorption Voltage (Fastest Recharge): 14.6 – 14.9 V
  • Float Voltage: 13.5 – 13.8 V
  • Storage Voltage: 13.2 – 13.5 V
  • Recommended Charge Current: Should preferably not exceed 0.2 C (12 A for this 60 Ah model).
  • Temperature Compensation: -24 mV/°C for a 12V battery (Required if battery temperature is expected to be < 10°C or > 30°C for long periods).

Mechanical Specifications

  • Dimensions (l x w x h): 229 x 138 x 227 mm
  • Weight: 20 kg
  • Terminals: Copper

Key Features

  • Excellent High Current Performance: Specifically recommended for heavy-load applications and engine starting.
  • VRLA Technology: Maintenance-free operation with safety valves to prevent excessive gas pressure and ensure long service life.
  • Adaptive Charging Support: Optimized for use with Victron adaptive chargers, which calculate variable absorption times and include a storage mode to reduce plate corrosion.

Victron 12V 60Ah AGM Deep Cycle Battery – Data Sheet

Battery Capacity 60A
Battery Type AGM
