Pytes Energy V5A Plus 51.2V 5.12kWh LiFePO₄ (LFP) battery module

Pytes Energy V5A Plus 51.2V 5.12kWh LiFePO₄ (LFP) battery module

110402100241

Brand: Pytes

Long Lifespan: Over 6,000 cycles at 90% DOD, backed by a 10-year warranty. Cold Weather Performance: Integrated heating system ensures operation in temperatures as low as -18°C. Remote Management: Monitor and upgrade firmware remotely via WiFi. Space-Efficient Design: Compact 3.2U form factor with 5.12kWh capacity. Flexible Scalability: Supports up to 491.52kWh in a single system, accommodating future energy needs.

In stock

This is pre-order - Available in 7 – 10 days

£1,152.44 GBP
£1,152.44 GBP
Sale Sold out

Product Details

Pytes V5°α Plus is a high-performance 51.2V 5.12kWh LiFePO₄ (LFP) battery module designed for residential energy storage applications. Engineered for reliability and efficiency, it offers over 6,000 cycles at 90% Depth of Discharge (DOD), ensuring long-term performance and a 10-year warranty. With a compact 3.2U form factor and weighing 45.34 kg, it's suitable for both wall and ground installations, making it ideal for homeowners seeking energy independence.

Key features include:

  • Integrated Heating System: Ensures optimal performance in temperatures as low as -18°C, making it suitable for colder climates.
  • Remote Monitoring & Upgrading: Allows users to monitor battery status and perform firmware updates remotely via WiFi.
  • High Energy Density: Provides 5.12kWh of energy in a compact design, maximising space efficiency.
  • Scalability: Supports up to 16 units (81.92kWh) per group and up to 6 groups (491.52kWh) in a system with a hub, accommodating growing energy needs.
  • Triple Safety Protections: Features overcurrent alarm, short circuit protection, and a 360A fuse, ensuring safe operation.

With certifications including UL9540A, UL1973, and CE, the V5°α Plus is compatible with most inverter brands on the market, offering flexibility and peace of mind for homeowners.

Product Specifications

Electrical Specifications

  • Chemistry: Lithium Iron Phosphate (LFP)
  • Nominal Voltage: 51.2 V
  • Voltage Range: 47.5 V – 57.6 V
  • Nominal Capacity: 100 Ah
  • Nominal Energy: 5.12 kWh
  • Recommended Charge/Discharge Current: 75 A
  • Maximum Continuous Charge/Discharge Current: 75 A
  • Peak Charge/Discharge Current (3 min): 101 A – 120 A
  • Peak Charge/Discharge Current (15 sec): 121 A – 200 A
  • Round-Trip Efficiency: ≥ 95%
  • Integrated Breaker: DC 125V / 125A

Performance & Longevity

  • Cycle Life: ≥ 6,000 cycles (90% DoD @ 25°C / 77°F)
  • Service Life: 20-year design life
  • Warranty: 10 years
  • Self-Consumption: < 170 W (Low power mode)

Mechanical & Installation

  • Dimensions (L x W x H): 484 x 578.2 x 140 mm (3.2U)
  • Weight: 45.34 kg (100 lbs)
  • Power Terminals: Amphenol SurLok Plus 8.0mm
  • Communication Protocols: CAN, RS485
  • Mounting Options: Rack-mount, Wall-mount, or Ground-mount (with optional battery tray)
  • Scalability: 16 units (81.92 kWh) per group; up to 6 groups (491.52 kWh) in a single system using a Hub.

Environmental Specifications

  • Operating Temperature Range: -10°C to 50°C (14°F to 122°F)
  • Storage Temperature Range: -20°C to 60°C (-4°F to 140°F)
  • Integrated Heating System: Automatically maintains optimal temperature for cold-weather performance.
  • Heating Pad Rise Rate: 10°C per hour (18°F per hour)
  • Heating Pad Operation Range: -18°C to 15°C (-0.4°F to 59°F)

Safety & Monitoring

  • Triple Safe Protections: Enhanced BMS, integrated DC breaker, and Emergency Shutdown (ESD).
  • Fire Suppression: Internal aerosol fire suppression system for industry-grade safety.
  • Remote Monitoring: Real-time monitoring and firmware upgrades via Web/App (Wi-Fi connection required).
  • Data Visualization: Error detection, alarm notifications, and real-time performance tracking.

Certifications & Compliance

  • Safety & Standards: UL9540 Ed.2 (2020), UL9540A, UL1973, CE, IEC62619
  • Environmental & Shipping: UN38.3

Pytes Energy V5A Plus 51.2V 5.12kWh LiFePO₄ (LFP) battery module – Manual

Pytes Energy V5A Plus 51.2V 5.12kWh LiFePO₄ (LFP) battery module – Data Sheet

Battery Capacity 100Ah
Voltage 51.2V
Battery Type Lithium
Depth of Discharge 90%
Cycle Life 6000
Protection IP20 - Indoor
Weight KG 45.34
Warranty Years 10
