Orion IP67 12/24-50A (1200W) DC-DC Converter
Orion IP67 12/24-50A (1200W) DC-DC Converter
SKU:ORI122421226
Brand: Victron
Completely waterproof: The unit is fully encased in resin, so water, oil or dirt will not cause any damage.
Built to last: A rugged cast aluminium casing protects the internal parts from vibrations and heavy shocks.
Extremely efficient: With a 96 percent efficiency rating, it converts power with almost no waste, meaning your batteries last longer.
Handles the heat: It is designed to work in hot environments like machine rooms and features built-in protection against overheating.
Stable power supply: It ensures a steady 24V output even if your main battery voltage fluctuates when other equipment starts up.
Safe and reliable: The converter includes protection against short circuits and will automatically recover after a fault is cleared.
In stock
This is pre-order - Available in 7 – 10 days
Regular price
£263.00 GBP
Regular price
Sale price
£263.00 GBP
Quantity
Couldn't load pickup availability
Product Details
Product Details
The ORI1224211226 is a non-isolated DC-DC converter that provides a massive 1200W of power. In practical terms, its 50A continuous output current makes it capable of running heavy-duty 24V loads that smaller converters simply cannot handle. The IP67 rating is a professional standard that confirms the unit is totally protected against dust and can even be submerged in water for short periods without harm.
Inside the unit, the electronics are entirely moulded in resin within a blue aluminium casing, which not only keeps out moisture but also makes the device ignition protected. This is a vital safety feature for marine engine rooms or any area where fuel vapours might be present. The design is intentionally simple to install, using M6 bolts for the main power connections to ensure a solid, vibration-proof link to your system.
Safety is a priority with this model. It features a hiccup mode for overload protection, meaning if the unit is pushed too hard, it will briefly pause and then automatically try to restart once the load is back to a safe level. It also operates across a huge temperature range, from a freezing -40 degrees Celsius up to a scorching +70 degrees Celsius, providing full power in temperatures up to 40 degrees Celsius. For peace of mind, this product is backed by a five-year standard warranty and global support.
Product Specifications
Product Specifications
Product Downloads
Product Downloads
Technical Specifications
Technical Specifications
| Protection | IP67 - Outdoor |
|---|
