Victron MultiPlus 48V 800VA Inverter/Charger
Victron MultiPlus 48V 800VA Inverter/Charger
SKU:PMP481800000
Brand: Victron
In stock
This is pre-order - Available in 7 – 10 days
Couldn't load pickup availability
Product Details
Product Details
The Victron MultiPlus 48V 800VA Inverter and Charger is a compact power solution designed for users who want reliable off grid capability without compromising on the quality of their AC supply. It provides clean, stable 230V power using a true sine wave inverter, making it suitable for a wide range of household appliances, tools, and electronics. Whether installed in a campervan, marine system, motorhome, or small off grid building, it delivers dependable power performance in a space saving format.
One of the standout benefits is its ability to switch between power sources without interruption. When shore power is available, connected appliances are supplied directly and the integrated battery charger restores energy reserves. If shore or generator input is lost, the MultiPlus switches to battery power in less than twenty milliseconds. This protects sensitive equipment such as computers, navigation systems, and communication devices from shutdown or data loss.
With a maximum charging current of 9A, the MultiPlus 48/800/9 provides efficient charging for leisure batteries. This makes it ideal for users operating modest AC loads totalling 800VA or less. The pure sine wave output accurately replicates domestic mains power, helping appliances run quietly and reducing strain on electronic circuitry. Many cheaper inverters produce modified waveforms that may cause noise, heat, or reduced lifespan in equipment, making pure sine wave output a key advantage.
For remote access, the MultiPlus supports optional connectivity through the VE.Bus smart dongle, allowing performance monitoring and configuration via the VictronConnect app. Alarms can be set for high or low battery voltage, giving improved oversight when equipment is left running unattended. When paired with devices such as the Color Control GX or Venus GX, owners can access enhanced system management tools.
Integration with the free VRM app and portal unlocks remote system visibility. From a phone, tablet, or laptop, users can review historical data, adjust settings, and check system performance from almost anywhere. This improved awareness helps prevent downtime and supports better battery management.
Designed around Victron’s well known reliability, this inverter charger provides stable power, charging intelligence, and flexible monitoring options. For smaller power systems where quality, protection, and efficiency are important, the MultiPlus 48V 800VA delivers long term value.
Product Specifications
Product Specifications
Inverter Specifications
- Input Voltage Range: 38 – 66 V
- Output Voltage: 230 VAC ± 2%
- Output Frequency: 50 Hz ± 0.1% (Adjustable to 60 Hz)
- Continuous Output Power at 25°C: 800 VA
- Continuous Output Power at 25°C: 700 W
- Continuous Output Power at 40°C: 650 W
- Continuous Output Power at 65°C: 400 W
- Peak Power: 1600 W
- Maximum Efficiency: 95%
- Zero-Load Power: 10 W
- Zero-Load Power (Search Mode): 2 W
Charger Specifications
- AC Input Voltage Range: 187 – 265 VAC
- Input Frequency: 45 – 65 Hz
- Charge Voltage 'Absorption': 57.6 V
- Charge Voltage 'Float': 55.2 V
- Storage Mode: 52.8 V
- Charge Current House Battery: 9 A
- Charge Current Starter Battery: n/a (available on 12V and 24V models only)
- Battery Temperature Sensor: Yes
Features & Connectivity
- PowerControl & PowerAssist: Yes
- Transfer Switch: 16 A
- Parallel and 3-Phase Operation: Up to six units can operate in parallel to achieve higher power output; three units can be configured for three-phase output. (Note: RJ45-splitter ASS030065510 is required for 800 VA models).
- Programmable Relay: Yes (Configurable for general alarm, DC under-voltage, or generator start/stop functions).
- Remote On-Off: Yes (On/Off/Charger only)
- Search Mode: Reduces power consumption by approximately 70% in no-load operation.
- DIP Switches: Yes (For setting remote switch, battery charge voltage, inverter frequency, and search mode).
- Remote Monitoring: Compatible with Cerbo GX or other GX products for monitoring via the VRM (Victron Remote Management) portal and VRM app.
Mechanical & Enclosure
- Dimensions (H x W x D): 375 x 214 x 110 mm
- Weight: 6.4 kg
- Material & Colour: Steel/ABS (Blue RAL 5012)
- Protection Category: IP21
- Battery Connection: 16 mm²
- 230V AC Connection: G-ST18i connector
- Internal DC Fuse: 30 A
Environmental & Standards
- Operating Temperature Range: -40 to +65°C (Fan-assisted cooling)
- Humidity: Max 95% (Non-condensing)
- Safety Standards: EN-IEC 60335-1, EN-IEC 60335-2-29, EN 62109-1
- Emission / Immunity: EN 55014-1, EN 55014-2, EN-IEC 61000-3-2, EN-IEC 61000-3-3, IEC 61000-6-1, IEC 61000-6-2, IEC 61000-6-3
- Automotive Directive: ECE R10-5
- Integrated Protections: Output short circuit, overload, battery voltage too high/low, temperature too high, 230 VAC on inverter output, and input voltage ripple too high.
Technical Specifications
Technical Specifications
| Inverter Rating | 800VA |
|---|
