Isolation Tr. 3600W Auto 115/230V
Isolation Tr. 3600W Auto 115/230V
SKU:ITR050362041
Brand: Victron
In stock
This is pre-order - Available in 7 – 10 days
Couldn't load pickup availability
Product Details
Product Details
The Victron Energy 3600W Auto Isolation Transformer is an indispensable component for professional marine and mobile power systems, providing superior electrical safety and protection against galvanic corrosion. This crucial device completely isolates your vessel's AC system from the shore power ground, eliminating the cause of electrolytic corrosion that can damage underwater metal parts.
Featuring automatic input voltage detection, this model intelligently switches to accommodate either a 115V or 230V AC shore supply. The output voltage is user configurable to provide either 115V or 230V power to your boat, making it perfect for international travel. Built with efficient, low noise toroidal wound technology and standard soft start circuitry, it prevents high inrush currents that can trip marina circuit breakers upon connection. Encased in a robust, blue aluminium housing (IP21), this transformer is the definitive solution for safe and reliable shore power connectivity.
Product Specifications
Product Specifications
Technical Specifications
Combined for SKUs: ITR050362041
A CInput Voltage: 115 or 230V
A COutput Current Rating115: 16 A
A COutput Current Rating230: 32 A
AC Output Voltage: 115 or 230V
Automatic ACInput Detection: Yes
Can Be Used As115Or230Transformer: Yes
Colour: Blue (RAL 5012)
Depth: 218 mm
Frequency: [50, 60] Hz
Height: 362 mm
Input Circuit Breaker: Yes
Material: Aluminium
Power Rating: 3,600
Protection Category: IP21
Safety: EN 60076
Soft Start: Yes
Transformer Type: Toroidal
Weight: 24 kg
Width: 258 mm
Source: Victron
