Isolation Tr. 3600W 115/230V
Isolation Tr. 3600W 115/230V
SKU:ITR040362041
Brand: Victron
In stock
This is pre-order - Available in 7 – 10 days
Couldn't load pickup availability
Product Details
Product Details
The Victron Energy Isolation Transformer 3600W 115/230V is a high‑performance transformer designed to provide galvanic isolation between shore power and onboard systems. This isolation helps prevent electrolytic corrosion and ensures a safe electrical system.
Featuring toroidal wound technology, the transformer operates quietly and efficiently. Its soft start circuitry ensures that the shore circuit breaker will not trip when plugged in.
The transformer is suitable for professional marine energy systems and other applications requiring reliable isolation.
Product Specifications
Product Specifications
Technical Specifications
Combined for SKUs: ITR040362041
A CInput Voltage: 115 or 230V
A COutput Current Rating115: 32 A
A COutput Current Rating230: 16 A
AC Output Voltage: 115 or 230V
Automatic ACInput Detection: No
Can Be Used As115Or230Transformer: Yes
Colour: Blue (RAL 5012)
Depth: 218 mm
Frequency: [50, 60] Hz
Height: 362 mm
Input Circuit Breaker: Yes
Material: Aluminium
Power Rating: 3,600 W
Protection Category: IP21
Safety: EN 60076
Soft Start: Yes
Transformer Type: Toroidal
Weight: 23 kg
Width: 258 mm
Source: Victron
