EasySolar-II 48/3000 – 3-In-1 Charge Controller, Inverter/Charger, GX Device
EasySolar-II 48/3000 – 3-In-1 Charge Controller, Inverter/Charger, GX Device
SKU:PMP482307010
Brand: Victron
In stock
This is pre-order - Available in 7 – 10 days
Couldn't load pickup availability
Product Details
Product Details
EasySolar-II 48/3000/35-32 MPPT 250/70 GX – PMP482307010
Effortless Solar Power Integration:
The Victron EasySolar-II 48/3000 seamlessly integrates an MPPT solar charge controller, an inverter/charger, and an intelligent control hub, streamlining your solar power solution with minimal wiring complexity. The GX device at its core serves as the central monitoring and communication center for your electrical system.
Key Features:
- All-in-One Solution: Combines an MPPT solar charge controller, Multiplus-II inverter/charger, and GX control device into a single, compact unit, simplifying installation and reducing wiring complexity.
- SmartSolar MPPT Charge Controller: Intelligently harnesses solar energy, optimizing energy harvest with the latest MPPT technology. Ensures swift full charge and promotes battery health for extended life.
- MultiPlus-II Inverter/Charger: Features a powerful pure sine wave inverter and sophisticated battery charger in a single unit. Converts 48V DC power to 230V AC, enabling up to 3000VA of off-grid appliance operation. Seamlessly switches power sources between hookup and leisure batteries, eliminating manual switching.
- GX Device Monitoring: The GX device serves as the communication hub, connecting and monitoring all system components and batteries. Enables both local and remote monitoring through the Victron Remote Management app and computer program (VRM). Allows remote firmware updates and configuration adjustments for the inverter/charger.
- Efficient Energy Harvest: SmartSolar MPPT charge controller optimizes energy collection, making it ideal for applications such as campervans, boats, and off-grid tiny houses.
- Seamless Power Source Switching: MultiPlus-II inverter/charger automatically switches between hookup and leisure batteries, providing uninterrupted power to mains appliances.
| Brand |
Victron Energy |
|---|---|
| Manufacturer Part Number |
PMP482307010 |
| gtin |
8719076045786 |
| Voltage |
48V |
| Cont. Output Power at 25°C |
3000VA |
| Peak Power |
5500W |
| Output AC Voltage |
230V |
| Transfer Switch |
32A |
| Max. AC Input Current |
32A |
| Max. Battery Charge Current |
32A |
| Protection Category |
IP21 |
| Efficiency |
99% |
| Bluetooth Compatible |
Yes |
| Dimensions |
H499 x W268 x D237mm |
| Weight |
26Kg |
| Warranty |
5 Years |
| Country of Manufacture |
India |
Product Specifications
Product Specifications
Technical Specifications
Combined for SKUs: PMP482307010
AC Input Frequency Range: [45, 65] Hz
AC Input Voltage Range: [187, 265] VAC
AC Output Frequency: 50 Hz
AC Output Voltage: 230 VAC
Anti Islanding Standard: See our website
Aux Ac Current: 32 A
Auxiliary Output: Yes
Battery Connection Terminal Type: M8 bolts
Battery Voltage Nominal: 48 V
Charge Algorithm: Adaptive, 4-stage
Charge Algorithm1: Adaptive, 4-stage
Charge Voltage Absorption: 57.6 VDC
Charge Voltage Absorption1: 57.6 VDC
Charge Voltage Float: 55.2 VDC
Charge Voltage Float1: 55.2 VDC
Charge Voltage Storage: 52.8 VDC
Colour: Blue (RAL 5012)
Communication Port: VE.Direct,VE.Bus,VE.Can,BMS-Can,WiFi,Ethernet
Computer Programming: Yes
Cont Power W55: 1,700 W
Continuous Power (VA, 25°C): 3,000 VA
Continuous Power (W, 25°C): 2,400 W
Continuous Power (W, 40°C): 2,200 W
DC Input Voltage Range: [38, 66] VDC
Depth: 237 mm
Emission Immunity: EN 55014-1,EN 55014-2,EN-IEC 61000-3-2,EN-IEC 61000-3-3,EN-IEC 61000-6-1, EN-IEC 61000-6-2,EN-IEC 61000-6-3
External Ac Current Sensor: 50A or 100A (optional)
Fan Assist Cooling: Yes
Height: 499 mm
Material: Steel
Max Ac Input Current: 32 A
Max Apparent Feed-in Power: 3,000 VA
Max Efficiency: 94 %
Max Humidity: 95 %
Max Output Current Solar: 70 A
Max Pv Open Circuit Voltage: 250 V
Max Pv Power: 4,000 W
Maxi Efficiency Solar Charger: 99 %
Maximum Battery Charge Current: 70 A
P VConnection Terminal Type: M6 bolts
Peak Power Rating: 5,500 W
Power Assist: Yes
Power Control: Yes
Programmable Relay: AC rating: 230V / 4A, DC rating: 4A up to 35VDC and 1A up to 60VDC
Protection Category: IP21
Protections: Output short-circuit,Overload,High battery voltage,Low battery voltage,Over temperature,AC voltage on inverter output,Excessive DC ripple
Relay Terminal: Screw terminal 3-pole
Remote Terminal: On / Off
Remote Terminal Type: Screw terminal two pole
Safety: EN-IEC 60335-1,EN-IEC 60335-2-29,EN-IEC 62109-1,EN-IEC 62109-2
Self Consumption: 20 mA
Solar Charger Model: MPPT 250/70-Tr
Temperature Sensor: Included
Transfer Switch Current Rating: 32 A
VE.Bus Terminal Type: Two RJ45 terminals
Weight: 26 kg
Width: 268 mm
Zero Load Power: 13 W
Zero Load Power (AES): 9 W
Zero Load Power (Search): 3 W
Source: Victron
Shipping & Collection
Shipping & Collection
Technical Specifications
Technical Specifications
| MPPT Amps | 70 |
|---|---|
| Inverter Rating | 3000VA |
